Type

Desktop

Engine speed

A4 (8 1/2" x 11")*1

Max. 24/22 ppm

A3 (11" x 17")

Max. 12 (11) ppm

Control panel display

5-line LCD

Paper size

Max. A3 (11" x 17"), min. A6*2 (5 1/2" x 8 1/2")

Paper capacity
(80 g/m2)

Standard

350 sheets
(250-sheet tray and 100-sheet multi bypass tray)

Maximum

1,850 sheets
(350 sheets & optional 3 x 500-sheet tray)

Paper weight

Tray 1

60 g/m2 to 105 g/m2 (16 lbs bond to 28 lbs bond)

Trays 2–4

60 g/m2 to 200 g/m2 (16 lbs bond to 110 lbs index)

Multi bypass tray

55 g/m2 to 200 g/m2 (13 lbs bond to 110 lbs index)

Warm-up time*3

25 sec.

Memory

1 GB (copy/print shared)

Power requirements

Rated local AC voltage ±10%, 50/60 Hz

Power consumption

Max. 1.2 kW

Dimensions (W x D x H)

599 x 608 x 643 mm
(23 19/32" x 23 15/16" x 25 21/64")

Weight (approx.)

34 kg (74.6 lbs)

Original paper size

Max. A3 (11" x 17")

First copy time*4

6.4 sec.

Continuous copy

Max. 999 copies

Resolution

Scan

400 x 600 dpi

Print

600 x 600 dpi

Gradation

Equivalent to 256 levels

Zoom range

25% to 400% (25% to 200% using RSPF) in 1% increments

Preset copy ratios

Metric

10 ratios (5R/5E)

Inch

8 ratios (4R/4E)

Scan method

Push scan (via control panel)
Pull scan (TWAIN-compliant application)

Scan speed*5

Colour & B/W

Max. 37 originals/min.

Resolution

Push scan

100, 150, 200, 300, 400, 600 dpi*6

Pull scan

75, 100, 150, 200, 300, 400, 600 dpi
50 dpi to 9,600 dpi via user setting*7

File formats

TIFF, PDF, JPEG*8

Scan destinations

Scan to email/desktop*9/FTP server/network folder (SMB)/USB drive

Resolution

600 x 600 dpi

Interface

USB 2.0 (host, high-speed), 10Base-T/100Base-TX/1000Base-T, wireless LAN (IEEE 802.11 b/g/n)*10

Supported OS

Windows Server® 2012, Windows Server® 2012 R2, Windows Server® 2016, Windows Server® 2019, Windows® 8.1, Windows® 10,
Mac OS 10.9, 10.10, 10.11, 10.12, 10.13, 10.14, 10.15

Network protocols

TCP/IP

Printing protocols

LPR, Raw TCP (port 9100), FTP for downloading print files, IPP, SMB, WSD

PDL

Standard

PCL 6 emulation

Option

PostScript® 3™ emulation

Available fonts

80 fonts for PCL, 136 fonts for PostScript 3 emulation
